Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 04/20/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x2UFixedRackShelf

• 4xM6CageNuts

• 4xM6Screws

• 1xInstructionManual

System Requirements

• EIA-310Ccompliant19inserverrack/cabinet

• Atleast2Uofavailablespaceinrack/cabinettomountshelf

• Ifusingarack/cabinetthatdoesnotusesquaremountingpointsalong

theposts,theappropriatemountinghardwarefortherackwillberequired

(consultdocumentationfortherackorcontactthemanufacturer)

Installation

1. Locateasuitablelocationintherack/cabinettomounttheshelf.

Theshelfitselfrequires2Uofspacewithintherack/cabinet.

2. Iftherackusessquaremountingholes,installtheincludedcage

nutsintothesquaremountingholesonthefrontpostsoftherack.

3. Placetheshelfintotherackandalignthemountingpointsonthe

frontbracketsoftheshelfwiththemountingpointsontherack

(e.g.thecagenuts,ifused).

4. Usetheprovidedcabinetscrewstosecuretheshelftotherack.If

notusingtheincludedcagenutsorM6threadedrackposts,the

appropriatemountinghardwarefortherackshouldbeused.

5. Makesurethescrewsareproperlytightenedandtheshelfhasno

movementbeforeattemptingtoplaceanythingontheshelf.Be

suretoobservethemaximumweightcapacityoftheshelf.

CABSHELFV/CABSHELF22/CABSHELF22V

2U 16in Depth Universal Vented Rack Mount Shelf - 50lbs / 22kg

2U 22in Depth Solid / Vented Fixed Rack Mount Shelf - 50lbs / 22kg

CABSHELF22

CABSHELFV

CABSHELF22V

1 2

Manual Revision: 04/20/2012 1
