Startechcom SAT2510BU2B Manuale Utente

USB 2.0 External Hard Drive Enclosure2.5” Black USB 2.0 SATA External Hard Drive Enclosurewith One Button BackupSAT2510BU2BInstruction Manual

StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans m

FCC Compliance StatementThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FC

iTable of ContentsIntroduction ... 1Packaging Contents...

1IntroductionPackaging Contents1 x SAT2510BU2B enclosure•1 x USB ‘Y’ Cable•1 x User Manual•1 x Software CD•System RequirementsUSB 2.0 enabled comp

2Place the HDD into the case and slide it into the SATA connector.2. Place the foam to fill up the gap between the HDD and enclosure. 3. Assemble the c

3Driver InstallationMicrosoft Windows® 2000 or later, and Mac OS® 10.x do not require driver installation, as this enclosure is natively supported.Ins

4pop-up windows then select “Options”. Check the Enable “One Touch Backup” column.Features1 One Touch Backup Button2 Ejection pinhole3 USB connector4

5SpecicationsInterfaceUSB 2.0 (backwards compatible with USB 1.x)External Connectors1 x USB type B1 x DC power connectorInternal Connectors1 x 7-pin

6Technical SupportStarTech.com’s lifetime technical support is an integral part of our com-mit-ment to provide industry-leading solutions. If
